vacuum oven

vacuum oven Specification

Type
Rectangular laboratory vacuum oven

Chamber Size
450 x 450 x 450 mm (approx)

Chamber Thickness
Approx 2.5 mm, stainless steel

Outer Size
640 x 630 x 690 mm (approx)

Compressed Air
Not applicable / Not required

Door Type
Single Transparent Tempered Glass Door with Vacuum Seal Gasket

Design Pressure
Atmospheric to -0.09 MPa (Vacuum)

Working Pressure
Vacuum, up to -0.09 MPa

Design Temperature
Up to 200C

Heat Uniform
2C uniformity

Insulation
High-grade thermal insulation with mineral wool

Net Weight
Approx 60 kg

Recording Parameters
Digital temperature controller with timer display

Spraying Mode
No spraying system

Steam
Not compatible for steam operation

Sterilizing Temperature
Adjustable as per process, typically up to 200C

Working Temperature
Up to 200C

Sterilization Time
Up to 99 hours, programmable

Temperature Scope
Ambient to 200C

Piping System
Stainless steel vacuum connection

Valves
Vacuum release and inlet air valve installed

Power Consumption
Approximately 1400 Watts

Control System
Microprocessor based PID temperature control

Chamber Material
Stainless Steel (304 grade)

Number of Shelves
2 or 3 removable shelves

Power Supply
220V, 50Hz single phase

Heater Type
Nichrome wire heating elements

Internal Finish
Polished stainless steel

Window Type
Double layered tempered glass for observation

Optional Accessories
Vacuum pump, digital data logger, extra shelves

Vacuum Pump
Compatible with external rotary vane vacuum pump (not included)

Safety Features
Over temperature protection, automatic cutoff

Sealing Material
Silicone gasket for vacuum tightness

Vacuum Gauge
Analog gauge fitted on front panel

About vacuum oven

Don't miss this hot deal on a distinguished laboratory vacuum oven crafted with polished 304-grade stainless steel. Its commanding chamber, sized at 450 x 450 x 450 mm, provides ample space with two or three removable shelves. This unbeatable oven features a microprocessor PID control system and a robust analog vacuum gauge. Equipped with safety essentials-over temperature protection, automatic cutoff, and double-layer tempered glass window-this is your last chance to claim a superior solution for precise thermal applications. Secure this high-performance deal today!

Versatile Applications & Extra Features

The vacuum oven is widely used for drying, degassing, curing, and sterilizing in laboratories, research institutions, and industrial settings. Its customizable chamber size, adjustable shelving, and compatibility with external rotary vane vacuum pumps make it adaptable for various processes. Additional features like over-temperature protection, a digital controller with timer, and optional accessories such as data loggers and extra shelves add to its versatility and distinguished performance.

Certifications, Order Processing & Shipment

Our vacuum ovens are offered with standard industry certifications for quality assurance. Order processing is swift and transparent, ensuring quick shipment and timely delivery according to your needs. We provide flexible payment terms for all orders. Upon confirmation, shipment tracking is provided, and delivery usually occurs within the stated timeframe. Don't miss the opportunity to secure this commanding oven-take advantage of this unbeatable offer now!

FAQ's of vacuum oven:

Q: How does the vacuum oven ensure uniform heating?

A: The vacuum oven utilizes high-grade thermal insulation and nichrome wire heating elements, ensuring uniform temperature distribution (2C) throughout the chamber.

Q: What applications can this vacuum oven be used for?

A: This oven is ideal for drying, sterilizing, degassing, baking, and curing processes in chemical labs, research facilities, and electronics industries.

Q: Where is the vacuum gauge located for easy monitoring?

A: The analog vacuum gauge is conveniently fitted on the front panel, allowing continuous observation and precise vacuum level adjustments during operation.

Q: What extra features and accessories are available with the vacuum oven?

A: Optional accessories such as a digital data logger, extra shelves, and a compatible external rotary vane vacuum pump enhance the oven's usability and data recording capabilities.

Q: When can I expect delivery after placing an order?

A: After order processing, shipment is arranged promptly, and delivery is usually completed within the agreed timeframe, depending on your location and payment confirmation.

Q: How is temperature controlled and monitored during use?

A: A highly accurate microprocessor-based PID temperature controller and timer display allow precise adjustments and real-time monitoring of both temperature and process time.
